Air conditioner manifold gauge VEVOR WZ-J403(SS), 4-way, 22 × 20 × 5.95 cm

VEVOR air conditioning manifold gauge set is designed for measuring and servicing the pressure of systems using R22, R404A, R410A and R12 refrigerants. It is suitable for servicing automotive, domestic and commercial air conditioning systems.

The four-way manifold has high and low pressure gauges, color-coded hoses and separate vacuum and refrigerant valves. Calibration screw, dual scale, temperature scale and observation window for measurement and charging work.

Main product features

• 4-way manifold gauge
• Supports R22, R404A, R410A and R12 refrigerants
• Color-coded rubber hoses
• Hose length: 1.5 m
• Brass fittings and aluminum valve body
• Rubber protective cap
• Calibration screw and dual scale gauges
• Working pressure range: 800-4000 PSI

Technical information

• Model: WZ-J403(SS)
• Valve body dimensions: 220 × 200 × 59.5 mm
• Weight: 2.05 kg

Complete set

• 4-way manifold gauge
• 4 rubber hoses, 1.5 m each
• Rubber protective cap
